SPECIFICATIONS
|
U.S. |
Metric |
| Concrete Output Per Hour (Rod/Piston) |
118/91 cu yds |
91/70 cu m |
| Maximum Pressure on Concrete (Rod/Piston) |
870/1568 psi |
60/108 bar |
| Maximum Aggregate Size |
2.5 in |
64 mm |
| Concrete Cylinder Diameter |
8 in |
200 mm |
| Concrete Cylinder Stroke Length |
63 in |
1600 mm |
| Differential Piston/Rod Diameter |
4.72/ 3.14 in |
120/ 80 mm |
| Outlet Diameter |
7 in |
180 mm |
| Concrete Valve Type |
M Rock™ |
| Shifting Cylinders |
2 |
| Max. Pump Strokes Per Minute (Rod/Piston) |
30/23 |
| Volume Control |
0 to Maximum |
| Hydraulic System |
Open Loop |
| Main Hydraulic Pump |
A11VLO190 |
| Hydraulic Pressure |
4350 psi |
300 bar |
| Hydraulic Tank Capacity |
105 gal |
397 l |
| Engine Model – Diesel Tier 4 F |
CAT® C4.4 |
| Engine Power |
173 hp |
129.5 kW |
| Fuel Tank Capacity |
65 gal |
246 l |
| Hopper Capacity |
21 cu ft |
0.6 cu m |
| Length |
20′ 8″ |
6.3 m |
| Width |
7′ 11″ |
2.4 m |
| Height |
8′ |
2.5m |
| Unit weight |
19,900 lbs |
9026 kg |
| Remote Control Cable |
100 ft |
30.5 m |
| *Pump specifications are for standard units. Other units are available. Specifications are subject to change without prior notice |
