Description
Drive system
- 70HP Hatz 4H50TIC turbo diesel engine complies with US EPA Tier 4 Final emission requirements
- Patented Engine Power Management senses engine load and adjusts hydraulic pump stroke to allow the engine to operate at peak performance
- Six-blade spider assemblies assure the flattest floors possible with 33% more blade contact
Operator controls
- Cruise control reduces operator fatigue during low-speed operations
- 6 LED lights provide state-of-the-art illumination for nighttime or indoor work
- Retardant spray system actuated by the controls located on the steering handles provides uniform coverage of the slab surface
- Proportional hydraulic steering has been enhanced and offers improved responsiveness with minimal operator effort
- SmartPitch™ control synchronizes blade pitch for both rotors with a single button
- The multifunction display provides the operator with easy-to-read data including engine speed, fuel levels, and alerts
- Rotor Jog facilitates lifting; allows the operator to jog the rotors to prevent surface marring while standing in front of the machine
- 12 Volt outlet and drink holder for charging your electronic devices and operator convenience
Design
- Clamshell design
Unit Specifications Engine Hatz 4H50TIC turbo diesel engine Engine Cooling liquid Blades per Rotor 6 Rotor RPM 10-130 Path Width 117 in 2971 mm Fuel Tank Capacity 20 gal 75.7 L Run Time 3.4 gal/hr Dimensions & Weights Overall Length 65 in 1651 mm Overall Width 125 in 3175 mm Overall Height 57 in 1447 mm Operating Weight 2544 lb 1158 kg Shipping Weight 3044 lb 1380 kg simplifies maintenance and permits convenient access to all service items
- Automatic Shut-down stops the rotors from turning if the operator stands up while the engine is running
- Increased chassis rigidity and stability achieved by a lower center of gravity, reduces body roll and improves steering feedback and operator control
Engines using diesel fuel should be operated only in areas with adequate ventilation. NEVER operate in confined areas or in areas where the free flow of air is restricted.
