U.S. |
Metric |
| Concrete Output Per Hour (Rod/Piston) |
148/ 97 cu yds |
113/ 74 cu m |
| Maximum Pressure on Concrete (Rod/Piston) |
1480/ 2350 psi |
102/ 162 bar |
| Maximum Aggregate Size |
2.5 in |
64 mm |
| Concrete Cylinder Diameter |
8 in |
200 mm |
| Concrete Cylinder Stroke Length |
79 in |
2000 mm |
| Differential Piston/Rod Diameter |
5.5 in |
140 mm |
| Outlet Diameter |
6 in |
150 mm |
| Concrete Valve Type |
RL Rock™ |
| Shifting Cylinders |
2 |
| Max. Pump Strokes Per Minute (Rod/Piston) |
30/ 20 |
| Volume Control |
0 to Maximum |
| Hydraulic System |
Open Loop |
| Main Hydraulic Pump |
— |
| Hydraulic Pressure (Rod/Piston) |
4785 psi |
330 bar |
| Hydraulic Tank Capacity |
— |
— |
| Engine Model- CAT Tier 4 F |
CAT® 9.3B |
| Diesel Engine Power |
416 hp |
310 kw |
| Fuel Tank Capacity |
105 gal |
397 l |
| Hopper Capacity |
21.2 cu ft |
0.6 cu m |
| Hopper-Height |
57.5 in |
1461 mm |
| Axle |
Single Standard Job Site |
| Axle Capacity Rating |
— |
— |
| Tires |
— |
| Brakes |
N/A |
| Outrigger Legs |
Hydraulic |
| Length |
24′ 3″ |
7.4 m |
| Width |
7′ 2″ |
2.2 m |
| Height |
9′ 5″ |
2.9 m |
| Trailer Units Weight |
20,500 lbs |
9300 kg |
| Remote Control Cable |
Cable-Pump Forward/ Stop/Reverse/E-Stop |
| *Pump specifications are for standard units. Other units are available. Specifications are subject to change without prior notice |
