Mayco C30HDGA

Mayco C30HDGA

Product Description

The Mayco C30HDGA is a strong and easy-to-use concrete pump made for tough job sites. It can pump up to 25 cubic yards (19 m³) per hour, making it great for small-aggregate concrete, masonry grout, shotcrete, and pressure grouting.

Description

The Mayco C30HDGA is a strong and easy-to-use concrete pump made for tough job sites. It can pump up to 25 cubic yards (19 m³) per hour, making it great for small-aggregate concrete, masonry grout, shotcrete, and pressure grouting.

This model runs on a 45-hp (33.5 kW) fuel-injected Zenith gasoline engine, giving you quiet, efficient, and reliable performance. It also offers better fuel economy and lower emissions. The pump handles materials with a maximum aggregate size of 1/2 inch (12 mm) for smooth, consistent flow.

The C30HDGA includes a 2-function 125-foot (37.5 m) hardwired remote. You can also choose an optional radio remote with full volume control for extra convenience.

For easier upkeep, the pump features a sealed piston lubrication box and a central grease station, helping protect key parts and extend their life.

Each unit comes with:

  • One 3-inch x 90° pipe elbow

  • One 3 x 2 x 28-inch reducer

  • Two 3-inch raised-end couplings

Built for performance and durability, the Mayco C30HDGA is a dependable choice for contractors who need a high-output, low-maintenance pump that gets the job done right.



Specifications

Unit Specifications
Pump Type Reciprocating piston
Hopper Capacity 6 ft³ 0.17 m³
Material Hose Diameter 3 in 76 mm
Pumping Specifications
Volume Output
per Hour*
25 yd³ 19 m³
Concrete Piston Face Pressure 500 psi
Max. Aggregate Size 0.5 in 12 mm
* These figures will vary due to concrete mix design, line size, and job site conditions.
Dimensions & Weights
Overall Length 144 in 3658 mm
Overall Width 59 in 1499 mm
Overall Height 65 in 1651 mm
Operating Weight 2920 lb 1325 kg
Shipping Weight 178 lb 126.3 kg
