U.S. |
Metric |
| Concrete Output Per Hour |
95 cu yds |
73 cu m |
| Maximum Pressure on Concrete |
942 psi |
65 bar |
| Maximum Aggregate Size |
1.5 in |
37 mm |
| Concrete Cylinder Diameter |
7 in |
180 mm |
| Concrete Cylinder Stroke Length |
55 in |
1400 mm |
| Differential Piston/Rod Diameter |
3.15/ 2.16 in |
80/ 55 mm |
| Outlet Diameter |
5 in |
125 mm |
| Concrete Valve Type |
Long Rock™ |
| Shifting Cylinders |
2 |
| Max. Pump Strokes Per Minute |
34 |
| Volume Control |
0 to Maximum |
| Hydraulic System |
Open Loop |
| Main Hydraulic Pump |
A11VLO130 |
| Hydraulic Pressure |
4785 psi |
330 bar |
| Hydraulic Tank Capacity |
112 gal |
424 l |
| Engine Model – Diesel Tier 4 F |
CAT® 4.4 |
| Engine Power |
173 hp |
129.5 kW |
| Fuel Tank Capacity |
53 gal |
200 l |
| Hopper Capacity |
13 cu ft |
.38 cu m |
| Hopper Height |
51 in |
1292 mm |
| Length |
20′ 1.5″ |
6129 mm |
| Width |
6′ 4″ |
1950 mm |
| Height |
7′ 11″ |
2167 mm |
| Unit Weight |
10600 lbs |
4808 kg |
| Dual Weight |
N/A |
N/A |
| Remote Control Cable |
100 ft |
30.5 m |
| *Pump specifications are for standard units. Other units are available. Specifications are subject to change without prior notice |
