U.S. |
Metric |
| Concrete Output Per Hour |
70 cu yds |
54 cu m |
| Maximum Pressure on Concrete |
1100 psi |
76 bar |
| Maximum Aggregate Size |
1.5 in |
38 mm |
| Concrete Cylinder Diameter |
7 in |
180 mm |
| Concrete Cylinder Stroke Length |
39 in |
1000 mm |
| Differential Piston/Rod Diameter |
3.54/ 1.96 in |
90/ 50 mm |
| Outlet Diameter |
5 in |
125 mm |
| Concrete Valve Type |
Long Rock™ |
| Shifting Cylinders |
2 |
| Max. Pump Strokes Per Minute |
35 |
| Volume Control |
0 to Maximum |
| Hydraulic System |
Open Loop |
| Main Hydraulic Pump |
A11VO130 |
| Hydraulic Pressure |
4350 psi |
300 bar |
| Hydraulic Tank Capacity |
112 gal |
424 l |
| Engine Model – Diesel Tier 4 F |
CAT® 4.4 |
| Engine Power |
137 hp |
102.2 kW |
| Fuel Tank Capacity |
39 gal |
148 l |
| Hopper Capacity |
13 cu ft |
.38 cu m |
| Hopper-Height |
51 in |
1292 mm |
| Length |
16′ 5″ |
4997 mm |
| Width |
6′ 4″ |
1950 mm |
| Height |
7′ 11″ |
2167 mm |
| Unit Weight (Tier 4) |
9300 lbs |
4218 kg |
| Dual Weight |
N/A |
N/A |
| Remote Control Cable |
100 ft |
30.5 m |
| *Pump specifications are for standard units. Other units are available. Specifications are subject to change without prior notice |
