U.S. |
Metric |
| Concrete Output Per Hour |
70 cu yds |
53.5 cu m |
| Maximum Pressure on Concrete |
1100 psi |
75.8 bar |
| Maximum Aggregate Size |
1.5 in |
38.1 mm |
| Concrete Cylinder Diameter |
7 in |
180 mm |
| Concrete Cylinder Stroke Length |
39 in |
1000 mm |
| Differential Piston/Rod Diameter |
3.5/ 1.96 in |
90/ 50 mm |
| Outlet Diameter |
5 in |
125 mm |
| Concrete Valve Type |
Long Rock™ |
| Shifting Cylinders |
2 |
| Max. Pump Strokes Per Minute |
35 |
| Volume Control |
0 to Maximum |
| Hydraulic System |
Open Loop |
| Main Hydraulic Pump |
A11VO130 |
| Hydraulic Pressure |
4350 psi |
300 bar |
| Hydraulic Tank Capacity |
112 gal |
424 l |
| Engine Model – Diesel Tier 4 F |
CAT® C4.4 |
| Engine Power |
137 hp |
102.2 kW |
| Fuel Tank Capacity |
39 gal |
147 l |
| Hopper Capacity |
13 cu ft |
.38 cu m |
| Hopper-Height |
51 in |
1292 mm |
| Axle |
Tandem Standard |
| Axle Capacity Rating |
11000 lbs |
4990 kg |
| Tandem Axle Tires |
ST 235/80 R16 (std.) |
| Brakes |
Electric |
| Outrigger Legs |
Manual Standard |
| Length |
200 in |
4840 mm |
| Width |
76 in |
1835 mm |
| Height |
94 in |
2400 mm |
| Unit Weight (Tier 4) |
9300 lbs |
4218 kg |
| Dual Weight |
N/A |
N/A |
| Remote Control Cable |
100 ft |
30.5 m |
| *Pump specifications are for standard units. Other units are available. Specifications are subject to change without prior notice |
